Capture the application
A four-step configurator collects dimensions, performance, options and contact details, supported by reference drawings and a 3D preview.
BUILT FOR LOAD CELL ENGINEERING TEAMS
Turn a load pin enquiry into a technical starting point.
Give your customers a guided way to configure their load pin. Receive a structured request, a preliminary FEM assessment and documentation ready for engineering review.
Experience your company’s demo →Private access · Your company name · 12 hours to explore
✓ Guided configuration✓ FEM screening✓ STEP + report
● LOAD PIN WORKSPACE01 / CONFIGURE
GEOMETRY → ANALYSIS → REVIEW
Illustrative integration geometry1 Geometry / 2 Performance / 3 Options / 4 Request
ONE STRUCTURED WORKFLOW
From dimensions to documentation. ↗Less time reconstructing the request. More context for the engineering decision.
THE WORK BEFORE THE QUOTATION
A custom load pin starts with questions.
Make the answers easier to collect.
Dimensions, load, output, cable routing, environment and documentation requirements often arrive across drawings, messages and follow-up calls.
Load Cell Designer brings those inputs into one guided request and adds a preliminary assessment, giving your team a clearer starting point for feasibility and quotation.
A WORKFLOW YOUR CUSTOMERS CAN FOLLOW
Configure. Assess. Review.
A simple customer journey, with the engineering detail delivered to your team.
Run preliminary screening
The calculation evaluates the design against the model’s criteria. It reports preapproval or explains why changes or technical review are needed.
Receive the review package
The request and available technical documents arrive by email. Preapproved designs also give the customer an integration STEP for their assembly.
TWO ROLES. THE RIGHT LEVEL OF DETAIL.
A useful response for the customer.
A technical package for your team.
CUSTOMER EXPERIENCE
A clear next step.
- Guided configuration and interactive 3D preview
- Screening outcome and result email
- Integration STEP for preapproved designs
- Public geometry without strain gauge pockets
YOUR ENGINEERING TEAM
The context to review.
- Structured application and requirements
- Detailed STEP for preapproved designs
- Engineering or diagnostic report when available
- Calculation record and customer attachments
Final feasibility, manufacturability and quotation remain with your team.
SEE IT WITH YOUR COMPANY NAME
Don’t just read about the workflow.
Put a request through it.
Activate a private demonstration and see exactly what arrives in your inbox.
Start your private demonstration →- Sign in securely
Protected by Cloudflare authentication.
- Make it yours
Enter your company name and verify your demo email.
- Explore for 12 hours
Up to five calculations. Both email roles go to your verified address.
- Automatic expiry
Access and deliveries stop. Demo records enter automatic deletion.
BEFORE YOU START
Engineering questions. Clear answers.
Does preapproval mean the pin is ready for manufacture?
Preapproval is preliminary linear-elastic screening. Your team must complete contact, fatigue, tolerance, manufacturability and certification checks before manufacturing.
What if no design is preapproved?
The platform presents available reasons and diagnostics for review. An inconclusive result does not establish that the pin cannot be manufactured.
Who receives demonstration emails?
The address verified during setup receives both engineering packages and customer receipt examples. Requests are not routed to the production inbox.
What happens after twelve hours?
Access, downloads and new delivery attempts stop. Demo records are purged on the next scheduled cleanup, normally within one minute. Received emails and provider retention are outside that purge. Read the privacy notice.
Can this be adapted to our business?
Discuss your product range, engineering rules, branding and integration needs with Marc & Structures to define an implementation scope.
